C++ Multiple Thread Concurrency with data in Classes

I was recently looking at Quora feed and someone asked the question: -

If a class in C++ has a member function that executes on a separate thread, can that member function read from and write to data members of the class?

which I thought would be a good question to answer. However, it’s not likely to be a short answer so I thought I would write a blog article on the subject.

I will start by saying that when dealing with multiple threads (often just referred to as concurrency), it’s actually a lot simpler than you might think, but it does take a certain mindset before it feels natural. Anyway, back to the answer to the question.

The short answer to the question is, No, not safely, not without adding some form of concurrency protection. Things are a lot easier in C++11 but like anything to do with concurrency, it all depends on your implementation details and the nature of the data members, their purpose and the reason for needing multiple threads to read/write to that data.

As a general (but not exclusively true) rule, having one instance of a class that contains dynamic data at runtime, should not be operated on by more than one thread. Many threads can read without issue, but modifying is generally a bad idea.

If you need to modify data of a class, give the thread that modifying the data exclusive access to that class instance, this, while not enforced or required by C++, adopting this strategy will most certainly help humans reading your code understand intent.

In this article I will cover two common patterns for dealing with this problem: copy-on-write with shared pointers (nearly lock-free) and mutex-based locking (explicit protection). Both have their place, and choosing between them depends on the nature of your data and access patterns.

Approach 1: Copy-on-Write with shared_ptr

One of my most frequently used patterns which is incredibly useful, and (almost) lock-free, and fast, and basically foolproof from a usability point of view and really simple to understand in a concurrent system. This is not the only solution, nor is it perfect for any situation, nor is it anything special, but it does really help in multi-threaded systems (servers especially).

Let’s say we have a class that contains some configuration information, for this purpose I will use a simple map of name/values

class config_data_t
{
   std::map<std::string, std::string> _config_vals;

public:
   const std::string& get_val(const std::string& name);
};

And this configuration is global, so we load it from a file and hold it in memory so that all threads can access the configuration information quickly and without having to worry about concurrency AND we have a thread that watches the config file, and if it changes, we need to reload our configuration information safely, without either locking or disrupting any other thread.

So the first thing we are going to need to do is to create a global instance of our config object and load it from the config file. To do this we are going to create a shared_ptr which is a global variable, make a new instance of our config class and load it with its data.

using config_data_ptr_t = std::shared_ptr<config_data_t>;
config_data_ptr_t _global_config_info;

void load_config()
{
   config_data_ptr_t config_info = std::make_shared<config_data_t>();

   // Do whatever you need to do in order to load the config_info->_config_vals with data

   // atomically update our global variable
   std::atomic_store(&_global_config_info, config_info);

   // ... rest of main() stuff
}

Ok, in the above code, we have a global variable _global_config_info shared pointer, then in main() we have made a new instance of a config_data_t object as a local shared pointer (config_info), populated it with data and finally, we have assigned our config_info pointer to our global _global_config_info pointer, at this point within the scope of load_config(), both config_info and _global_config_info are pointing to the same instance of the config class, when load_config ends, config_info goes out of scope leaving the config info pointed to by the _global_config_info shared pointer.

Within our program we want any thread to be able to access our configuration information, so we provide a global getter function to make this easy and intuitive.

config_data_ptr_t config()
{
    return std::atomic_load(&_global_config_info);
}

This is a very simple function, but this is where half of the magic happens. What we are doing is atomically loading the shared pointer, which gives us a new shared pointer pointing to the same instance of the config_data_t class as the _global_config_info pointer. We use std::atomic_load here because a plain read of a shared_ptr is not thread-safe if another thread is simultaneously writing to the same variable — the reference count operations are atomic, but the shared_ptr object itself is not. Using atomic_load/atomic_store ensures the read and write of the global pointer are safe. Once you have your own copy of the pointer, you may access configuration values as required. This can be done safely from as many threads as you like, without fear of any concurrency issues.

const config_data_ptr_t cfg = config();

const std::string& val = cfg->get_val("some.config.val");

Now I said above, this is “half” the magic, because there is a rule you need to follow… you must never, under any circumstances modify the values held in the global config object, if you do, your thread(s) will run into concurrency issues. So if you load it and use it, no problem. But we said that we also need to be able to detect changes to the config file and load those changes when detected! Well, that’s the other half of the magic, because we are going to take advantage of the shared_ptr behavior and we are going to follow one simple rule…

We will never change the config values in a config object, if we detect a change in the configuration file we will simply re-load it.

if(has_config_file_changed())
{
   load_config();
}

At the point we call load config, other threads might have a pointer to the current config, but when we load the config into a new instance of the config_data_t class, and then we assign this pointer to the global pointer, the second half of the magic occurs. All existing threads that have a config pointer are pointing to the old instance (pre config file changes) of the config object, the global pointer gets updated to point to the freshly loaded config object. As each thread finishes with the config the shared_ptrs go out of scope, when the last shared_ptr of the old config object goes out of scope, the old config object is freed from memory. Subsequent threads that call config() will get a pointer to the freshly loaded config object.

So this is the basic principle and it works really well, and I bet there is even a known “pattern” but if there is, I have no idea what its called. Also, there are two unanswered questions that the above raises.

What if I want my program to be able to modify configuration changes on the fly?

Absolutely this is a common requirement and it’s easy, you simply adopt the same principle, you never write changes to the config object that is pointed to by the global variable, instead, you simply take a copy of the global object, make your changes and replace the global object with your changes object.

std::mutex _global_config_mtx;

void set_config_values(const std::map<std::string, std::string>& vals)
{
  // Lock to prevent concurrent read-modify-replace races
  std::lock_guard<std::mutex> lock(_global_config_mtx);

  // Make a new empty config object
  config_data_ptr_t config_info = std::make_shared<config_data_t>();

  // Make a copy of the current global config
  *config_info = *config();

  // Modify config items as required
  for(const auto& v : vals)
    config_info->_config_vals[v.first] = v.second;

  // Atomically update our global variable
  std::atomic_store(&_global_config_info, config_info);
}

Surely copying a whole config object is really expensive if you just want to change a single value?

Yes and no, it depends on the nature of your data. If the configuration data is huge, then yes, this would not be the right pattern, but in my experience, most config data has some fundamental characteristics.

a) the configuration does not change much. b) the configuration is generally quite small from a size and a number of items point of view.

As I said, this pattern is not for all situations, generally, the copy pattern is a play-off between simplicity and efficiency. What I hope this example highlights though, is that class members are not in any way protected from concurrency issues, you need to adopt a pattern/strategy that gives you the best results for the job you are trying to do.

But what about when copy-on-write isn’t efficient — when the data is large, or you’re making frequent modifications? That’s where the second approach comes in.

Approach 2: Mutex-Based Locking

The second approach uses a mutex to protect the data within the class from multiple threads. One of the main things you want to do when dealing with threading and concurrency with data is to encapsulate and localise the locking in one place so the details of locking are completely hidden from the user of the class.

The rules to follow for this pattern are very simple…

• The data variables must be private within the class
• The mutex that protects the data must also be private to the class
• You should never return const references to your data in member functions, which means you must return copies of the data you need to access. This is ok for basic types but for strings and more complex types will mean copying data, or using shared pointers. I will cover both examples.

So, let’s start with making a basic class like before, the goal of the class is to contain a list of config params (key/value pairs) and to provide a 100% thread-safe interface to read/set values in this data set.

class config_data_t
{
   std::map<std::string, std::string> _config_vals;
   mutable std::mutex _config_vals_mtx;

public:
   std::string get_val(const std::string& name) const
   {
      // Lock our data, prevent any other thread while we are here
      std::lock_guard<std::mutex> locker(_config_vals_mtx);

      auto v = _config_vals.find(name);
      if(v !=  _config_vals.end())
         return v->second;
      return "";
   }

   void set_val(const std::string& name, const std::string& val)
   {
      // Lock our data, prevent any other thread while we are here
      std::lock_guard<std::mutex> locker(_config_vals_mtx);

      _config_vals[name] = val;
   }
};

This should be self-explanatory, the getter and setter function acquire an exclusive lock before touching the _config_vals private member. The implementation is 100% thread-safe because only one thread can operate on the _config_vals data at any one time.

You will note that the get_val() function returns a std::string by value, the string copy happens within the locked section.

Handling Large Data with shared_ptr

Now let’s take a look at what happens if the above class was working with larger data value sizes, for this example I have replaced the std::string with a blob_t which could, for example, be any data size from 60k to 10Mb of data. The following modified class uses this new type

class config_data_t
{
   using blob_t = std::vector<char>;
   std::map<std::string, blob_t> _config_vals;
   mutable std::mutex _config_vals_mtx;

public:
   blob_t get_val(const std::string& name) const
   {
      // Lock our data, prevent any other thread while we are here
      std::lock_guard<std::mutex> locker(_config_vals_mtx);

      auto v = _config_vals.find(name);
      if(v !=  _config_vals.end())
         return v->second;
      return {};
   }

   void set_val(const std::string& name, const blob_t& val)
   {
      // Lock our data, prevent any other thread while we are here
      std::lock_guard<std::mutex> locker(_config_vals_mtx);

      _config_vals[name] = val;
   }
};

Both the setter and getter are going to make copies of this data, and that would be a horrible implementation if the data sizes are large. In this case, I would want to implement this differently, and this is where the magic of std::shared_ptr comes into play, so let us re-work the above and discuss it below.

class config_data_t
{
   using blob_t = std::vector<char>;
   using blob_ptr_t = std::shared_ptr<const blob_t>;
   std::map<std::string, blob_ptr_t> _config_vals;
   mutable std::mutex _config_vals_mtx;

public:
   blob_ptr_t get_val(const std::string& name) const
   {
      // Lock our data, prevent any other thread while we are here
      std::lock_guard<std::mutex> locker(_config_vals_mtx);

      auto v = _config_vals.find(name);
      if(v !=  _config_vals.end())
         return v->second;
      return nullptr; // Or throw an exception if you prefer
   }

   void set_val(const std::string& name, blob_ptr_t&& val)
   {
      // Lock our data, prevent any other thread while we are here
      std::lock_guard<std::mutex> locker(_config_vals_mtx);

      _config_vals[name] = std::move(val);
   }
};

Now the change is quite subtle, but the overall performance of this will be much better, and still 100% thread-safe, essentially through the interface we are aiming to eliminate data copies. This is also using features that were introduced in C++11 so please be aware of this.

Ok, let’s start with the data storage, we now have a map of names to shared pointers, where the shared pointer is pointing to (and owning) a std::vector containing some arbitrarily large size of data. So first, let’s look at the get_val() which is now returning a shared pointer to one of the data items in the map. We are still doing a copy, but all we are copying is the pointer, not the data it points to. So once you call this get_val() function, the same block of data is now pointed to by both the shared pointer that was returned to you AND the pointer held in the _config_vals map. The data that is returned to you should be treated as a const value, in other words you must not modify or change the data in the vector that your pointer points to - this is critical. If you need to change a value you must call set_val() instead.

When you call set_val() you are passing in a pointer to a data block that you created, and what we do here is pass the shared_ptr in by R-Value, which allows us to take ownership of the data block you have already created, removing the need for a data copy. If a value already exists for that key, the old shared_ptr in the map is replaced — and if no other thread is still holding a copy of it, the old data is freed.

Now let us suppose, the value we are setting, already has another value set, and - that other value was previously obtained by you, so you are holding a shared_ptr to it. Now, when you set a new value, the pointer in the map to the old data is destroyed, but because there is another pointer to that same data, the data itself remains until the last instance of a shared_ptr is destroyed.

So the principle here, like the copy-on-write approach, you essentially never change data you already have a reference to, you simply replace it each time you do a change. This is what the shared_ptr is for and this pattern makes for a very thread-safe implementation.

Which Approach Should You Use?

Both patterns share a common principle: never modify data that other threads might be reading. The difference is in how they achieve it.

Use the copy-on-write approach (Approach 1) when:

• The data is read frequently but modified rarely
• The data set is relatively small (configuration, settings)
• You want near lock-free performance for readers
• You can afford to copy the entire object on write

Use the mutex-based approach (Approach 2) when:

• The data is modified frequently
• Individual values are large (use shared_ptr to avoid copies)
• You need fine-grained control over individual values
• The data set is too large to copy on every write

Final Thought

This is very basic stuff, but you will be surprised how many times I have seen this done badly, even by me… it’s simple if you keep the rules simple and it is unlikely to go wrong if your user can use the class without having to think about threading/concurrency issues at all.

What I hope these examples highlight is that class members are not in any way protected from concurrency issues. You need to adopt a pattern and strategy that gives you the best results for the job you are trying to do. Whichever approach you choose, the key is to encapsulate the concurrency protection so that users of your class never have to think about it.
